panasonic npm-d3a placement machine

The advantages and functions of Panasonic NPM-D3A placement machine mainly include the following aspects:

High production efficiency: NPM-D3A adopts dual-track mounting method, with a mounting speed of up to 171,000 cph and a unit productivity of 27,800 cph/㎡. In high production mode, the speed can reach 46,000 cph (0.078 s/chip) ‌

‌Wafer placement‌: The placement accuracy (Cpk≧1) is ±37 μm/chip, ensuring extremely high placement accuracy ‌

Wide range of applicable components: NPM-D3A can handle components from 0402 chips to L 6×W 6×T 3, supports 4/8/12/16mm braid width component power supply, and can provide up to 68 types of component power supply

‌Good base size compatibility‌: The base size range of dual-track type is L 50×W 50 ~ L 510×W 300, and the single-track type is L 50×W 50 ~ L 510×W 590, meeting the needs of multiple motherboard sizes ‌

‌Quick replacement‌: The dual-track replacement time can reach 0s in some cases (not 0s when the cycle time is less than 3.6s), and the single-track replacement time is 3.6s (when the short-type conveyor is selected) ‌

‌Versatility and flexibility‌: NPM-D3A inherits Panasonic's DNA of real-time installation features, is fully compatible with CM series hardware, has the ability to correspond to 0402-100×90mm components, and has functions such as component thickness inspection and substrate bending inspection. It can encapsulate the quality of mounting and fully meet customers' needs for high-throughput processes such as POP and flexible module improvement ‌‌

‌Humanized interface design‌: With a humanized interface design, the machine model switching indication can save the time of wasted material rack trolley exchange operations ‌

‌Remote operation and maintenance notification service‌: By remotely operating from the central control room, the operation time of on-site operators is reduced and the operation rate is improved. In addition, a maintenance notification service is provided for 360 days after the end of the maintenance period to help customers better maintain their equipment
