Gkg g5 smt stencil printer

GKG G5 solder paste printer is a high-performance fully automatic solder paste printing equipment suitable for the production and manufacturing of a variety of electronic products. ‌

Technical parameters and performance characteristics

The main technical parameters and performance characteristics of the GKG G5 solder paste printer include:

‌Printing size‌: 50x50mm to 400x340mm‌

‌PCB specifications‌: thickness 0.6mm to 6mm‌

‌Solder paste printing range‌: including 03015, 01005, 0201, 0402, 0603, 0805, 1206 and other specifications and sizes‌

‌Application range‌: Suitable for the production and manufacturing of mobile phones, communication equipment, LCD TVs, set-top boxes, home theaters, automotive electronics, medical power equipment, aerospace and other products Manufacturing ‌

Transmission speed‌: Maximum 1500mm/s‌

Printing accuracy‌: ±0.025mm, repeatability ±0.01mm‌

Printing cycle‌: Less than 7.5 seconds (excluding printing and cleaning time)‌

Cleaning method‌: Three modes: dry, wet, and vacuum‌

Vision system‌: Up and down imaging vision system, digital camera, geometric matching positioning, system alignment accuracy and repeatability ±12.5um@6σ, CPK≥2.0‌

User evaluation and market positioning

GKG G5 solder paste printer has a high evaluation in the market, mainly due to its high performance and stability. User feedback shows that the equipment has excellent performance in high-speed motion platform, automatic visual position recognition and compensation, and integrated temperature control technology, reducing manual intervention and improving production efficiency and accuracy‌ In addition, the equipment also has fault sound and light alarm and menu display functions, which further improves the safety and convenience of operation‌
