Siplace SX2 Pick and Place Machine for PCB Prototype and SMT Assembly

Brief: SMD, SMT Chip Mounter
Details

1. Preferred mounting scheme for small batch multi variety SMT production

2. Siplacesx series focuses on scalability and flexibility. Customers can quickly import new products and quickly change settings without stopping the line
3. It can produce products of any batch size to improve availability and efficiency.
4. Whether it is used in automobile, automation, medical treatment, telecommunications or IT infrastructure - siplacesx series can meet the requirements of quality,

All requirements such as process reliability and speed

5. Siplacesx becomes the first mounting solution that can be fully expanded according to needs with the unique exchangeable cantilever. Increase capacity when needed,

Reduce production capacity when order volume decreases. We call it SIPLACE capacity expansion on demand.

Model	Siplace SX2
PCB Specifications
Gantries	2 pcs
PCB format	L50×W50mm to L850×W560mm
PCB thickness	0.3×6.5mm
PCB weight	Approx 3 kg
IPC Capability Theoretical value	74,000CPH
IPC Capability Theoretical value	86,900CPH
Mounting Accuracy	Placement accuracy :±41μm/3σ(C&P)~±34μm/3σ(P&P)
Mounting Accuracy	Angular accuracy :±0.2°/3σ(C&P)~±0.1°/3σ(P&P)
Conveyor type	Single lane, Flexible dual lane
Conveyor mode	Asynchronous - Synchronous
Component Spectrum	01005 -50X40mm²
Mounting head characteristics	MultiStar
Feeder capacity	120 8mmx feeders
Equipment
External imensions	1.5x2.4m
Weight	Approx 950kgs
